L2194 - Grating

L15
NB
L2194

201 Square Nickel Bronze Direct Connection Grating, for use with tiles, marble, terrazzo, resin etc. flooring (Standard square grating), with 110.2 dia. vertical outlet

Additional Information:

Weight 3.9kg

Grating free area 156cm²

Standard square grating

Durable, superbly finished items particularly suited to a high volume of pedestrian traffic.

1
£310.40
