L3601 - Grating

L15
SS
L3601

200 Square Stainless Steel Vari-Level Grating, (Anti-slip mesh for use with flexible sheet floor covering, such as vinyl - grating not secured), with 4" NPSM dia. Vertical outlet with 23mm grating aperture width

Additional Information:

Weight 2.8kg

Grating free area 150cm²

Anti-slip mesh for use with sheet floor covering, such as vinyl - grating not secured.

For use in high specification applications including food preparation and areas where high corrosion resistance is a requirement.

1
£179.20
